前言
這次對布局進行優化,主要包含了首頁tabview pageview 以及添加幾個按鈕的操作過程.主要使用到stack層疊布局,tabpview和pageview,tabview兩個頁面,一個關注,一個推薦,左右切換,pageview被包含在tabview裏面.
布局優化
抖音的頂部appbar 是懸浮層疊展示,而flutter的層疊組件是stack, 因此最外面採用stack, 其次中間是tabview,分別是關注和推薦兩個選項卡,關注在沒有登錄的時候會彈出一個提示需要認證登錄的頁面,這裏加了兩個頁面,subscriptionScreen.dart,另外一個是loginScreen.dart
@override
Widget build(BuildContext context) {
return Scaffold(
//backgroundColor: Colors.transparent,
body: Stack(
//fit: StackFit.expand,
children: <Widget>[
TabBarView(
controller: _tabController,
children: <Widget>[
Subscription(),
PageView(
allowImplicitScrolling: true,
controller: _pageController,
children: <Widget>[
Trending(),
],
onPageChanged: (int index) {
setState(() {
currentIndex = index;
});
},
),
],
),
Column(
children: [
AppBar(
backgroundColor: Colors.transparent,
elevation: 0,
centerTitle: true,
leading: IconButton(
icon: Icon(Icons.tv),
onPressed: () {
print('點擊了直播按鈕');
}),
actions: <Widget>[
//導航欄右側菜單
IconButton(
icon: Icon(Icons.search),
onPressed: () {
print('點擊了搜索按鈕');
}),
],
title: TabBar(
indicator: UnderlineTabIndicator(
borderSide: BorderSide(width: 2.0, color: Colors.white),
insets: EdgeInsets.symmetric(horizontal: 18.0)),
labelStyle: TextStyle(fontSize: 18),
isScrollable: true,
controller: _tabController,
tabs: toptabs,
onTap: (index) {
print(index);
},
),
)
],
),
],
),
bottomNavigationBar: bottomItems(),
);
}
底部彈出提示認證頁面
在 onTap 方法里
Scaffold.of(context).showBottomSheet<void>((BuildContext context) {
return Login();
});
BottomSheet 是一個底部滑出的組件
new BottomSheet(
onClosing: () {},
builder: (BuildContext context) {
return new Text('aaa');
},
),
通常很少直接使用 BottomSheet 而是使用 showModalBottomSheet。直接時候的時候看到的知識 builder 里的內容。
Future<T> showModalBottomSheet <T>({
@required BuildContext context,
@required WidgetBuilder builder
});
看一個示例
new MaterialButton(
color: Colors.blue,
child: new Text('點我'),
onPressed: () {
showModalBottomSheet(
context: context,
builder: (BuildContext context) {
return new Container(
height: 300.0,
child: new Image.network(this.imgurl),
);
},
).then((val) {
print(val);
});
具體詳細介紹參考官網.
關注頁面
整個頁面布局,左右都有邊距,頂部也有邊距,所有採用Container包含,邊距使用padding: EdgeInsets.only(top: 150.0, left: 65.0, right: 65.0), 背景顏色 color: Color.fromRGBO(14, 15, 26, 1),依次image,另外使用sizebox佔用空間,
※網頁設計一頭霧水該從何著手呢? 台北網頁設計公司幫您輕鬆架站!
當全世界的人們隨著網路時代而改變向上時您還停留在『網站美醜不重要』的舊有思維嗎?機會是留給努力改變現況的人們,別再浪費一分一秒可以接觸商機的寶貴時間!
其他的中間層都是居中,所以採用center都是居中,另外登錄按鈕是佔滿屏幕的,所以也採用SizeBox,並且把width:設置為double.infinity,這樣就佔滿屏幕,button採用默認的RaisedButton,在button的onpressed事件調用showBottomSheet
import 'package:flutter/material.dart';
import 'package:flutter_app/Screens/loginScreen.dart';
class Subscription extends StatefulWidget {
@override
State<StatefulWidget> createState() => _SubscriptionState();
}
class _SubscriptionState extends State<Subscription>
with TickerProviderStateMixin {
final GlobalKey<ScaffoldState> scaffoldKey = GlobalKey<ScaffoldState>();
@override
Widget build(BuildContext context) {
return Container(
padding: EdgeInsets.only(top: 150.0, left: 65.0, right: 65.0),
color: Color.fromRGBO(14, 15, 26, 1),
child: Column(
crossAxisAlignment: CrossAxisAlignment.start,
children: <Widget>[
Image(image: AssetImage("assets/images/int_1581491273221.png")),
SizedBox(height: 20),
Center(
child: Text(
'你還沒有登錄',
style: TextStyle(
color: Colors.white,
fontSize: 20.0,
fontWeight: FontWeight.w400),
),
),
SizedBox(height: 10),
Center(
child: Text(
'登錄賬號,查看你關注的精彩內容',
style: TextStyle(
color: Color.fromRGBO(253, 253, 253, 0.6),
fontSize: 14.0,
fontWeight: FontWeight.w400),
),
),
SizedBox(height: 20),
SizedBox(
width: double.infinity,
child: RaisedButton(
color: Color.fromRGBO(252, 1, 86, 1),
child: Text(
'登錄',
style: TextStyle(color: Colors.white),
),
onPressed: () {
Scaffold.of(context)
.showBottomSheet<void>((BuildContext context) {
return Login();
});
},
),
),
]),
);
}
}
登錄頁面
布局如下圖:
這個頁面整體布局頂部,左右都有邊距,因此使用Container比較合適,設置背景顏色為color: Colors.white, 邊距設置為padding:EdgeInsets.only(top: 25.0, left: 25.0, right: 25.0, bottom: 50.0),整體布局採用Column,因為是上下布局,因此Column 設置
crossAxisAlignment: CrossAxisAlignment.start,頂部的布局是左邊一個clear圖標按鈕,右邊一個幫助按鈕,所以使用
Row布局,並且設置Row的mainAxisAlignment: MainAxisAlignment.spaceBetween,這樣就左右布局了,其他依次採用SizeBox佔位, 中間則採用Center來展示文字控件,底部的登錄部分因為包含標籤 超鏈接,所有採用RichText比較合適,包含TextSpan即可.
全部代碼如下:
import 'package:flutter/gestures.dart';
import 'package:flutter/material.dart';
import 'package:url_launcher/url_launcher.dart';
class Login extends StatefulWidget {
@override
State<StatefulWidget> createState() => _LoginState();
}
class _LoginState extends State<Login> {
TapGestureRecognizer _myTapGestureRecognizer;
@override
void initState() {
super.initState();
_myTapGestureRecognizer = TapGestureRecognizer()
..onTap = () {
launch('https://open.douyin.com/platform');
};
}
@override
void dispose() {
_myTapGestureRecognizer.dispose();
super.dispose();
}
@override
Widget build(BuildContext context) {
return Container(
color: Colors.white,
padding:
EdgeInsets.only(top: 25.0, left: 25.0, right: 25.0, bottom: 50.0),
child: Column(
crossAxisAlignment: CrossAxisAlignment.start,
children: [
Row(
mainAxisAlignment: MainAxisAlignment.spaceBetween,
children: [
IconButton(
icon: Icon(Icons.clear),
onPressed: () {
Navigator.pop(context);
},
color: Colors.black,
),
Text('幫助', style: TextStyle(color: Colors.black)),
],
),
SizedBox(
height: 150.0,
),
Center(
child: Text('180****2520',
style: TextStyle(color: Colors.black, fontSize: 38)),
),
Center(
child: Text('認證服務由中國電信提供',
style: TextStyle(
color: Color.fromRGBO(53, 53, 53, 1), fontSize: 12)),
),
SizedBox(
height: 50.0,
),
SizedBox(
width: double.infinity,
child: RaisedButton(
color: Color.fromRGBO(252, 1, 86, 1),
child: Text(
'本機號碼一鍵登錄',
style: TextStyle(color: Colors.white),
),
onPressed: () {
showBottomSheet(
context: context, builder: (context) => Login());
},
),
),
SizedBox(
height: 2.0,
),
SizedBox(
width: double.infinity,
child: OutlineButton(
color: Color.fromRGBO(252, 1, 86, 1),
child: Text(
'其他手機號碼登錄',
style: TextStyle(color: Colors.black),
),
onPressed: () {
showBottomSheet(
context: context, builder: (context) => Login());
},
),
),
SizedBox(
height: 5.0,
),
Center(
child: RichText(
text: TextSpan(
children: [
TextSpan(
text: '登錄即表明同意',
style: TextStyle(color: Color.fromRGBO(53, 53, 53, 0.8)),
),
TextSpan(text: ' '),
TextSpan(
text: '用戶協議',
style: TextStyle(color: Color.fromRGBO(0, 164, 219, 0.8)),
),
TextSpan(text: ' '),
TextSpan(
text: '和',
style: TextStyle(color: Color.fromRGBO(53, 53, 53, 0.8)),
),
TextSpan(text: ' '),
TextSpan(
text: '隱私政策',
style: TextStyle(color: Color.fromRGBO(0, 164, 219, 0.8)),
),
],
),
)),
Center(
child: RichText(
text: TextSpan(
children: [
TextSpan(
text: '以及',
style: TextStyle(color: Color.fromRGBO(53, 53, 53, 0.8)),
),
TextSpan(text: ' '),
TextSpan(
text: '《中國電信認證服務條款》',
style: TextStyle(color: Color.fromRGBO(0, 164, 219, 0.8)),
recognizer: _myTapGestureRecognizer),
],
),
)),
Expanded(
flex: 1,
child: Center(
heightFactor: 25.0,
child: Text('其他方式登錄',
style:
TextStyle(color: Color.fromRGBO(0, 164, 219, 0.8))))),
],
),
);
}
}
變更記錄
本次變更主要體現在首頁的選項卡設計,需要層疊展示,並且透明的採用appbar显示出頂部的關注、推薦按鈕,另外新增了關注頁,登錄頁,並且把底部按鈕以及右邊的按鈕都加上了觸發時間
接下來要完成的雙擊心形按鈕點贊,評論頁面,分享頁面,這些都可以採用showmodalbottomsheet方法打開一個底部抽屜頁面
還有底部的首頁刷新,消息頁面,拍短視頻頁面,消息頁面,我的個人信息頁面
結語
請繼續關注本博客,其他頁面持續更新完成,源碼地址:https://github.com/WangCharlie/douyin,歡迎fork和star,謝謝!!!
